- Public Address and Commercial Audio Systems
The compact models give systems designers increased flexibility by offering vastly improved music playback, additional coverage patterns and higher output in attractive paintable enclosures. Both models include front-loaded LF drivers in highly reinforced enclosures for natural, nonreasoning low frequency reproduction, whileidentical voicing ensures a uniform listening experience.
Features:
Ordering Code:
RC-10V: 250W@8ohm ; 150W@100V
RC-10V IP : 250W IP Net audio, Powered
RC-10V SIP : 250W SIP Net audio, Powered
RC-12V: 400W@8ohm; 250W@100V
RC-12V IP : 400W IP Net audio, Powered
RC-12V SIP : 400W SIP Net audio, Powered
RC-15V: 600W @8ohm; 400W @100V
RC-15V IP : 600W IP Net audio, Powered
RC-15V SIP : 600W SIP Net audio, Powered
|
Model
|
RC-10V
|
RC-12V
|
RC-15V
|
|
Rated power
|
250W@8ohm ; 150W@100V
|
400W@8ohm; 250W@100V
|
600W @8ohm; 400W @100V
|
|
Maximum power
|
500W
|
800W
|
1200W
|
|
Input
|
8ohm/100V
|
8ohm/100V
|
8ohm/100V
|
|
Sensitivity (1W/1M)
|
99dB / 96dB ± 3dB
|
99dB / 96dB ± 3dB
|
100dB / 99dB ± 3dB
|
|
Sensitivity Max
|
119dB / 116dB ± 3dB
|
124dB / 121dB ± 3dB
|
127dB / 124dB ± 3dB
|
|
Frequency response
|
70Hz-20KHz
|
70Hz-20KHz
|
70Hz-20KHz
|
|
Material
|
Fiber glass body, Metal frame
|
Fiber glass body, Metal frame
|
Fiber glass body, Metal frame
|
|
Speaker unit
|
10” 75VC bass + 44 VC treble
|
12” 75VC bass + 44 VC treble
|
15” 75VC bass + 75 VC treble
|
|
Product size
|
630*450*450mm
|
760*580*580mm
|
760*580*580mm
|
|
Weight
|
26KG
|
33KG
|
35KG
|
