Network Switch with 24 POE Ports

Twenty-four 10/100/1000M adaptive RJ45 ports support IEEE 802.3af/at standard PoE power supply.
Single port power supply up to 30W, total power supply up to 600W.
Support full-duplex based on IEEE802.3x and half-duplex based on Backpressure.
Gigabit RJ45 ports and SFP fiber ports combination, high-speed high-bandwidth connection, to meet the networking needs of various scenarios.

Model	POE24P30
Transmission Rate	10/100/1000Mbps
Max. Power Per Port	30W; IEEE802.3af/at/bt
Total Power	600W
Fixed Port	2410/100/1000Base-T PoE ports (Data /Power) 21000Base-X uplink SFP ports (Data)
Ethernet Port	Port 1-24 support 10/100/1000Base-T(X) auto-sensing, full/ half duplex MDI/ MDI-X self-adaption
Network Protocol	IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE802.3x
Switching Capacity	52Gbps
Power Supply	AC100~240V 50-60Hz
Dimension (LWH)	44029044.5mm
Net Weight	3.2kg
